Flutter CI/CD 与发布流程

胡新宇

发布于 2026-05-22

系统讲解Flutter GitHub Actions/Codemagic CI配置、iOS证书与Android签名、Fastlane自动化及灰度发布策略

Flutter CI/CD 与发布流程

Flutter CI/CD 与发布流程 (CI/CD & Release)

模块:模块十 · 架构与工程化
前置知识:Flutter 构建命令、Git 基础、测试基础


Flutter 多环境配置

使用 --dart-define 区分环境

# 三套环境(开发/测试/生产)
# 使用 --dart-define 传递编译时常量(比 .env 文件更安全,不会打入 APK)

# 开发环境
flutter run \
  --dart-define=ENV=development \
  --dart-define=API_URL=https://dev-api.example.com \
  --dart-define=ENABLE_LOGS=true

# 测试环境
flutter run \
  --dart-define=ENV=staging \
  --dart-define=API_URL=https://staging-api.example.com \
  --dart-define=ENABLE_LOGS=true

# 生产环境
flutter build apk \
  --dart-define=ENV=production \
  --dart-define=API_URL=https://api.example.com \
  --dart-define=ENABLE_LOGS=false \
  --release
// lib/core/config/app_config.dart
class AppConfig {
  // 从编译时常量读取,若未定义使用默认值
  static const String env = String.fromEnvironment(
    'ENV',
    defaultValue: 'development',
  );

  static const String apiUrl = String.fromEnvironment(
    'API_URL',
    defaultValue: 'https://dev-api.example.com',
  );

  static const bool enableLogs = bool.fromEnvironment(
    'ENABLE_LOGS',
    defaultValue: true,
  );

  // 便捷 getter
  static bool get isProduction => env == 'production';
  static bool get isDevelopment => env == 'development';
  static bool get isStaging => env == 'staging';
}

Android Flavor(更完整的多环境支持)

// android/app/build.gradle
android {
    flavorDimensions "environment"

    productFlavors {
        development {
            dimension "environment"
            applicationIdSuffix ".dev"      // com.example.app.dev
            versionNameSuffix "-dev"
            resValue "string", "app_name", "MyApp (Dev)"
        }

        staging {
            dimension "environment"
            applicationIdSuffix ".staging"  // com.example.app.staging
            versionNameSuffix "-staging"
            resValue "string", "app_name", "MyApp (Staging)"
        }

        production {
            dimension "environment"
            // 不添加后缀:com.example.app
            resValue "string", "app_name", "MyApp"
        }
    }
}
# 构建指定 Flavor
flutter build apk --flavor development --dart-define=ENV=development
flutter build apk --flavor production --dart-define=ENV=production --release
// lib/main_development.dart
void main() {
  runApp(const App(config: DevelopmentConfig()));
}

// lib/main_production.dart
void main() {
  runApp(const App(config: ProductionConfig()));
}

GitHub Actions 构建流水线

完整的 CI 配置

# .github/workflows/ci.yml
name: Flutter CI

on:
  push:
    branches: [main, develop]
  pull_request:
    branches: [main]

env:
  FLUTTER_VERSION: '3.19.0'

jobs:
  # ─── Job 1:代码检查 ───────────────────────────
  analyze:
    name: 代码分析
    runs-on: ubuntu-latest

    steps:
      - uses: actions/checkout@v4

      - name: 设置 Flutter
        uses: subosito/flutter-action@v2
        with:
          flutter-version: ${{ env.FLUTTER_VERSION }}
          cache: true                    # 缓存 Flutter SDK

      - name: 缓存 pub 依赖
        uses: actions/cache@v3
        with:
          path: ~/.pub-cache
          key: ${{ runner.os }}-pub-${{ hashFiles('**/pubspec.lock') }}
          restore-keys: |
            ${{ runner.os }}-pub-

      - run: flutter pub get
      - run: flutter analyze            # Dart 静态分析
      - run: dart format --check .      # 代码格式检查

  # ─── Job 2:测试 ───────────────────────────────
  test:
    name: 运行测试
    runs-on: ubuntu-latest
    needs: analyze                      # 依赖代码分析通过

    steps:
      - uses: actions/checkout@v4

      - name: 设置 Flutter
        uses: subosito/flutter-action@v2
        with:
          flutter-version: ${{ env.FLUTTER_VERSION }}
          cache: true

      - run: flutter pub get

      - name: 运行测试(含覆盖率)
        run: flutter test --coverage --reporter=github

      - name: 上传覆盖率报告
        uses: codecov/codecov-action@v3
        with:
          token: ${{ secrets.CODECOV_TOKEN }}
          files: coverage/lcov.info

  # ─── Job 3:构建 Android ─────────────────────────
  build-android:
    name: 构建 Android
    runs-on: ubuntu-latest
    needs: test

    steps:
      - uses: actions/checkout@v4

      - name: 设置 Java
        uses: actions/setup-java@v3
        with:
          java-version: '17'
          distribution: 'temurin'

      - name: 设置 Flutter
        uses: subosito/flutter-action@v2
        with:
          flutter-version: ${{ env.FLUTTER_VERSION }}
          cache: true

      - run: flutter pub get

      # 解码 Keystore(从 GitHub Secrets 读取 Base64 编码的 keystore)
      - name: 解码签名 Keystore
        run: |
          echo "${{ secrets.KEYSTORE_BASE64 }}" | base64 -d > android/app/release.keystore

      - name: 构建 Android App Bundle
        run: |
          flutter build appbundle \
            --flavor production \
            --dart-define=ENV=production \
            --dart-define=API_URL=${{ secrets.PROD_API_URL }} \
            --obfuscate \
            --split-debug-info=./debug-symbols \
            --release
        env:
          KEYSTORE_PATH: release.keystore
          KEYSTORE_PASSWORD: ${{ secrets.KEYSTORE_PASSWORD }}
          KEY_ALIAS: ${{ secrets.KEY_ALIAS }}
          KEY_PASSWORD: ${{ secrets.KEY_PASSWORD }}

      - name: 上传构建产物
        uses: actions/upload-artifact@v3
        with:
          name: android-release
          path: build/app/outputs/bundle/productionRelease/
          retention-days: 7

  # ─── Job 4:构建 iOS ──────────────────────────────
  build-ios:
    name: 构建 iOS
    runs-on: macos-14              # 必须用 macOS Runner
    needs: test

    steps:
      - uses: actions/checkout@v4

      - name: 设置 Flutter
        uses: subosito/flutter-action@v2
        with:
          flutter-version: ${{ env.FLUTTER_VERSION }}
          cache: true

      - run: flutter pub get

      # 安装 Apple 证书和 Provisioning Profile
      - name: 安装签名证书
        uses: apple-actions/import-codesign-certs@v2
        with:
          p12-file-base64: ${{ secrets.IOS_P12_CERT_BASE64 }}
          p12-password: ${{ secrets.IOS_P12_PASSWORD }}

      - name: 安装 Provisioning Profile
        uses: apple-actions/download-provisioning-profiles@v1
        with:
          bundle-id: com.example.app
          issuer-id: ${{ secrets.APPSTORE_ISSUER_ID }}
          api-key-id: ${{ secrets.APPSTORE_KEY_ID }}
          api-private-key: ${{ secrets.APPSTORE_PRIVATE_KEY }}

      - name: 构建 iOS
        run: |
          flutter build ipa \
            --flavor production \
            --dart-define=ENV=production \
            --obfuscate \
            --split-debug-info=./debug-symbols \
            --release \
            --export-options-plist=ios/ExportOptions.plist

      - name: 上传构建产物
        uses: actions/upload-artifact@v3
        with:
          name: ios-release
          path: build/ios/ipa/

自动发布到应用商店

CD 配置(发布到 Google Play + App Store)

# .github/workflows/release.yml
name: Flutter Release

on:
  push:
    tags:
      - 'v*.*.*'    # 触发条件:推送 vX.Y.Z 格式的 tag

jobs:
  release:
    name: 发布到应用商店
    runs-on: macos-14
    needs: [build-android, build-ios]   # 需要构建完成

    steps:
      # ─── 发布到 Google Play ────────────────────
      - name: 发布到 Google Play
        uses: r0adkll/upload-google-play@v1
        with:
          serviceAccountJsonPlainText: ${{ secrets.GOOGLE_PLAY_SERVICE_ACCOUNT }}
          packageName: com.example.app
          releaseFiles: android-release/*.aab
          track: internal              # internal → alpha → beta → production
          status: completed
          whatsNewDirectory: changelogs/  # 版本更新说明

      # ─── 发布到 App Store ──────────────────────
      - name: 发布到 TestFlight
        uses: apple-actions/upload-testflight-build@v1
        with:
          app-path: ios-release/*.ipa
          issuer-id: ${{ secrets.APPSTORE_ISSUER_ID }}
          api-key-id: ${{ secrets.APPSTORE_KEY_ID }}
          api-private-key: ${{ secrets.APPSTORE_PRIVATE_KEY }}

Fastlane 自动化签名

Android Fastlane 配置

# android/fastlane/Fastfile
default_platform(:android)

platform :android do
  desc "发布到 Google Play 内测轨道"
  lane :internal do
    # 自动递增版本号
    increment_version_code(
      gradle_file_path: "app/build.gradle"
    )

    # 构建 AAB
    gradle(
      task: "bundle",
      flavor: "production",
      build_type: "Release",
      properties: {
        "android.injected.signing.store.file" => ENV["KEYSTORE_PATH"],
        "android.injected.signing.store.password" => ENV["KEYSTORE_PASSWORD"],
        "android.injected.signing.key.alias" => ENV["KEY_ALIAS"],
        "android.injected.signing.key.password" => ENV["KEY_PASSWORD"],
      }
    )

    # 上传到 Google Play
    upload_to_play_store(
      track: 'internal',
      aab: "app/build/outputs/bundle/productionRelease/app-production-release.aab"
    )
  end
end

iOS Fastlane 配置

# ios/fastlane/Fastfile
default_platform(:ios)

platform :ios do
  desc "同步证书(使用 Match 管理)"
  lane :certificates do
    # Match:团队共享证书管理(存储在私有 Git 仓库)
    match(
      type: "appstore",
      app_identifier: "com.example.app",
      readonly: ENV["CI"] == "true"    # CI 环境只读,不重新生成
    )
  end

  desc "发布到 TestFlight"
  lane :beta do
    certificates

    # 自动递增 Build Number
    increment_build_number(
      build_number: latest_testflight_build_number + 1
    )

    build_app(
      scheme: "Runner",
      configuration: "Release-production",
      export_method: "app-store"
    )

    upload_to_testflight(
      skip_waiting_for_build_processing: true
    )
  end
end

iOS 签名证书链

Apple 签名体系:
┌─────────────────────────────────────┐
│  Apple Root CA                       │ 根证书(Apple 持有)
│    └── Apple WWDR CA                 │ 中间证书(自动信任)
│          └── Developer Certificate   │ 开发者证书(你创建)
│                                       │
│  Provisioning Profile                 │ 配置文件(绑定以下内容)
│  ├── App ID (Bundle Identifier)       │ com.example.app
│  ├── Developer Certificate           │ 与上面的证书关联
│  ├── Entitlements (权限)              │ Push Notifications, iCloud 等
│  └── Device UDIDs (开发/Ad-hoc)      │ 允许安装的设备
└─────────────────────────────────────┘

证书类型:
- Development:真机调试用
- Distribution (App Store):App Store 发布用
- Ad-hoc:指定设备测试用(最多 100 台)
- Enterprise:企业内部分发用

版本号管理策略

// pubspec.yaml 版本号格式
version: 2.3.1+42
//        │ │ │ └── Build Number(整数,每次发布递增)
//        │ │ └──── Patch(Bug 修复)
//        │ └────── Minor(新功能,向后兼容)
//        └──────── Major(破坏性变更)

// 语义化版本(Semantic Versioning)
// - MAJOR.MINOR.PATCH
// - 对应 Android versionName / iOS CFBundleShortVersionString
// + 后面的数字 = Build Number
// - 对应 Android versionCode / iOS CFBundleVersion
# 自动化版本管理脚本
#!/bin/bash
# scripts/bump_version.sh

PUBSPEC="pubspec.yaml"
CURRENT=$(grep "^version:" $PUBSPEC | cut -d' ' -f2)
VERSION=$(echo $CURRENT | cut -d'+' -f1)
BUILD=$(echo $CURRENT | cut -d'+' -f2)

NEW_BUILD=$((BUILD + 1))
NEW_VERSION="${VERSION}+${NEW_BUILD}"

# 更新 pubspec.yaml
sed -i '' "s/^version: .*/version: ${NEW_VERSION}/" $PUBSPEC

echo "版本从 $CURRENT 更新到 $NEW_VERSION"

Shorebird:热更新(Code Push)

# Shorebird 是 Flutter 的 Code Push 解决方案
# 允许在不经过 App Store 审核的情况下更新 Dart 代码

# 安装 Shorebird CLI
curl --proto '=https' --tlsv1.2 https://raw.githubusercontent.com/shorebirdtech/shorebird/main/install.sh -sSf | bash

# 初始化项目
shorebird init

# 创建发布版本(替代 flutter build)
shorebird release android
shorebird release ios

# 推送热更新补丁(无需重新审核)
shorebird patch android
shorebird patch ios

Shorebird 的限制:

能更新不能更新
Dart 代码逻辑Native 代码(Kotlin/Swift)
UI 布局Flutter 引擎版本
业务逻辑资源文件(图片/字体)
状态管理代码Manifest/Info.plist

完整发布流水线

代码提交 → PR 创建
     │
     ▼
[CI] lint + analyze(~2min)
     │
     ▼
[CI] 单元测试 + Widget 测试(~5min)
     │
     ▼(全部通过)
     │
     ├── Push to develop → 构建 staging 包 → 发布到 Firebase App Distribution(内测)
     │
     └── Tag v*.*.* → 构建 release 包 → 发布到 Google Play(internal)+ TestFlight
                                    ↓
                              人工确认(promote to production)
                                    ↓
                              Google Play Production + App Store Review

过关标准

✅ 能配置多 flavor(dev/staging/prod)的构建变体
✅ 能搭建一条从代码提交到应用商店发布的完整 CI/CD 流水线
✅ 能解释 iOS 签名的证书链关系(Root CA → WWDR CA → Developer Cert → Provisioning Profile)
✅ 能配置 --dart-define 传递环境变量并在代码中读取
✅ 理解 Shorebird Code Push 能更新什么、不能更新什么
