structuredClone 与序列化边界

胡新宇

发布于 2026-05-21

详解structuredClone算法支持的类型与不支持的类型、与JSON.parse对比、递归循环引用处理及深拷贝完整方案

structuredClone 与序列化边界

结构化克隆算法支持的类型(Map/Set/Date/RegExp/ArrayBuffer/Error 等)与不支持的类型(Function/DOM 节点/Symbol/原型链);与 JSON.parse(JSON.stringify()) 的对比;postMessage、IndexedDB、History API 中的隐式使用。


目录

  1. 结构化克隆算法(SCA)
  2. structuredClone API
  3. 支持 vs 不支持的类型
  4. 与 JSON 深拷贝的对比
  5. 隐式使用场景
  6. 深拷贝方案全景对比
  7. 手写验证:深拷贝边界测试
  8. 何时仍需手写深拷贝
  9. 深度追问

结构化克隆算法(SCA)

结构化克隆算法(Structured Clone Algorithm)是 HTML 规范定义的一套深拷贝标准,用于在不同上下文(Worker、IndexedDB 等)之间传递数据。

设计目标

  • 支持比 JSON 更丰富的类型(循环引用、类型化数组、Date、Map 等)
  • 不支持无法被序列化的类型(函数、DOM 节点)
  • 正确处理循环引用(记忆已克隆节点,不无限递归)

算法核心步骤

1. 维护一个"已访问"Map:original → clone(处理循环引用)
2. 检查值类型:
   - 原始值 → 直接返回
   - 可克隆对象 → 创建新实例,递归克隆属性
   - Transferable → 转移(不克隆)
   - 不可克隆 → 抛出 DataCloneError
3. 对象属性只克隆"自有可枚举"属性(不克隆原型链方法)

structuredClone API

structuredClone() 是 Web 标准的全局函数(浏览器和 Node.js 17+ 均支持),直接使用结构化克隆算法。

// 基础用法
const original = {
  name: 'Alice',
  scores: [100, 95, 88],
  meta: { joined: new Date('2020-01-01') }
};

const clone = structuredClone(original);

// 完全独立的深拷贝
clone.scores.push(99);
clone.meta.joined.setFullYear(2021);

console.log(original.scores.length); // 3(不受影响)
console.log(original.meta.joined.getFullYear()); // 2020(不受影响)
console.log(original === clone); // false

Transferable 支持

// transfer 选项:指定要转移(而非克隆)的对象
const buffer = new ArrayBuffer(1024);
const view   = new Uint8Array(buffer);
view[0] = 42;

const cloned = structuredClone(
  { data: buffer, name: 'test' },
  { transfer: [buffer] } // buffer 被转移
);

console.log(buffer.byteLength);         // 0(已转移,被 detached)
console.log(cloned.data.byteLength);    // 1024
console.log(new Uint8Array(cloned.data)[0]); // 42

支持 vs 不支持的类型

✅ 支持克隆的类型

const testClone = structuredClone({
  // 基本类型
  number:  42,
  string:  'hello',
  boolean: true,
  null_:   null,
  undefined_: undefined,
  bigint:  9007199254740993n,

  // 内置对象
  date:    new Date(),
  regexp:  /abc/gi,
  error:   new Error('test'),

  // 集合
  map:     new Map([['key', 'value']]),
  set:     new Set([1, 2, 3]),
  mapNested: new Map([[{}, new Set([1, 2])]]),

  // 类型化数组 & Buffer
  buffer:  new ArrayBuffer(8),
  u8:      new Uint8Array([1, 2, 3]),
  f64:     new Float64Array([Math.PI]),
  dataView: new DataView(new ArrayBuffer(4)),
  blob:    new Blob(['hello']),

  // 结构
  array:   [1, [2, [3]]],
  object:  { a: { b: { c: 1 } } },
});

// 循环引用
const circular = {};
circular.self = circular;
const clonedCircular = structuredClone(circular); // ✅ 不会栈溢出
console.log(clonedCircular.self === clonedCircular); // true(保持循环结构)

❌ 不支持克隆的类型(抛出 DataCloneError)

// ① 函数
try {
  structuredClone({ fn: () => {} });
} catch (e) {
  console.log(e.name); // "DataCloneError"
}

// ② DOM 节点
try {
  structuredClone(document.body);
} catch (e) {
  console.log(e.name); // "DataCloneError"
}

// ③ Symbol(键或值)
try {
  structuredClone({ [Symbol('id')]: 1 });
} catch (e) {
  console.log(e.name); // "DataCloneError"
}
try {
  structuredClone(Symbol('id'));
} catch (e) {
  console.log(e.name); // "DataCloneError"
}

// ④ Proxy(会克隆底层对象,但丢失 Proxy 行为)
const proxy = new Proxy({ x: 1 }, {
  get(t, k) { console.log('get', k); return t[k]; }
});
const cloned = structuredClone(proxy); // 克隆的是 { x: 1 },无 Proxy
// cloned.x 不会触发 get trap

// ⑤ WeakMap / WeakSet / WeakRef
try {
  structuredClone(new WeakMap());
} catch (e) {
  console.log(e.name); // "DataCloneError"
}

⚠️ 克隆时丢失原型链

class Point {
  constructor(x, y) {
    this.x = x;
    this.y = y;
  }
  distance() {
    return Math.sqrt(this.x ** 2 + this.y ** 2);
  }
}

const p = new Point(3, 4);
const cloned = structuredClone(p);

console.log(p.distance());      // 5(✅)
console.log(cloned.distance);   // undefined(❌ 原型方法丢失)
console.log(cloned instanceof Point); // false
console.log(Object.getPrototypeOf(cloned) === Object.prototype); // true

与 JSON 深拷贝的对比

全面对比表

特性structuredCloneJSON.parse(JSON.stringify())
Date✅ 保留 Date 类型❌ 变成字符串
RegExp✅ 保留❌ 变成 {}
Map/Set✅ 保留❌ 变成 {} / []
undefined✅ 保留❌ 属性被删除
NaN/Infinity✅ 保留❌ 变成 null
循环引用✅ 支持❌ 抛出错误
函数❌ 抛出 DataCloneError❌ 属性被删除
原型链❌ 丢失❌ 丢失
Symbol 键❌ 抛出 DataCloneError❌ 忽略
BigInt✅ 支持❌ 抛出 TypeError
性能较慢(更安全)快(针对简单对象)
Error✅ 保留 message/stack❌ 变成 {}

代码对比

const original = {
  date:     new Date('2024-01-15'),
  regex:    /hello/gi,
  map:      new Map([['key', 42]]),
  set:      new Set([1, 2, 3]),
  undef:    undefined,
  nan:      NaN,
  infinity: Infinity,
  fn:       () => 'hello',     // 函数
};

// structuredClone
let scClone;
try {
  scClone = structuredClone(original);
} catch (e) {
  console.log('structuredClone 失败:', e.message);
  // "DataCloneError: () => 'hello' could not be cloned."
}

// JSON
const jsonClone = JSON.parse(JSON.stringify(original));
console.log({
  date:     jsonClone.date,          // "2024-01-15T00:00:00.000Z"(字符串!)
  regex:    jsonClone.regex,         // {}(丢失!)
  map:      jsonClone.map,           // {}(丢失!)
  set:      jsonClone.set,           // (丢失,变成空数组或{})
  undef:    'undef' in jsonClone,    // false(属性被删除!)
  nan:      jsonClone.nan,           // null(变成 null!)
  infinity: jsonClone.infinity,      // null
  fn:       'fn' in jsonClone,       // false(函数被忽略!)
});

隐式使用场景

结构化克隆在以下 API 中自动使用,开发者不需要手动调用:

1. postMessage(Web Workers)

// 发送时序列化,接收时反序列化
worker.postMessage({ data: someObject }); // 内部使用结构化克隆

2. IndexedDB

// 存储和读取时自动序列化/反序列化
const store = db.transaction('items', 'readwrite').objectStore('items');
store.add({ date: new Date(), map: new Map() }); // Date 和 Map 正确保存

3. History API

// state 对象使用结构化克隆序列化
history.pushState({ user: { id: 1 }, visited: new Date() }, '', '/page');
// ⚠️ 函数和 DOM 节点不能放入 state!

4. Notification API

new Notification('提醒', { data: { id: 1, tags: new Set(['urgent']) } });

5. MessageChannel

const { port1, port2 } = new MessageChannel();
port1.onmessage = ({ data }) => console.log(data);
port2.postMessage({ value: new Date() }); // 自动克隆

深拷贝方案全景对比

/**
 * 深拷贝方案汇总
 */

// 方案 1:JSON 序列化(最快,但限制多)
const json = (obj) => JSON.parse(JSON.stringify(obj));

// 方案 2:structuredClone(推荐,原生支持)
const sc = (obj) => structuredClone(obj);

// 方案 3:Lodash cloneDeep(兼容最广,但需要引入库)
import { cloneDeep } from 'lodash-es';

// 方案 4:手写深拷贝(可定制,应对特殊场景)
function deepClone(value, seen = new WeakMap()) {
  // 原始类型和 null
  if (value === null || typeof value !== 'object' && typeof value !== 'function') {
    return value;
  }

  // 循环引用检测
  if (seen.has(value)) return seen.get(value);

  // 函数:直接返回引用(无法复制)
  if (typeof value === 'function') return value;

  // 特殊内置类型
  if (value instanceof Date)   return new Date(value.getTime());
  if (value instanceof RegExp) return new RegExp(value.source, value.flags);
  if (value instanceof Error)  {
    const e = new value.constructor(value.message);
    e.stack = value.stack;
    if (value.cause) e.cause = deepClone(value.cause, seen);
    return e;
  }

  // 类型化数组
  if (ArrayBuffer.isView(value)) {
    return new value.constructor(value.buffer.slice(0));
  }
  if (value instanceof ArrayBuffer) return value.slice(0);

  // Map
  if (value instanceof Map) {
    const cloned = new Map();
    seen.set(value, cloned);
    for (const [k, v] of value) {
      cloned.set(deepClone(k, seen), deepClone(v, seen));
    }
    return cloned;
  }

  // Set
  if (value instanceof Set) {
    const cloned = new Set();
    seen.set(value, cloned);
    for (const v of value) {
      cloned.add(deepClone(v, seen));
    }
    return cloned;
  }

  // 数组
  if (Array.isArray(value)) {
    const cloned = [];
    seen.set(value, cloned);
    for (let i = 0; i < value.length; i++) {
      cloned[i] = deepClone(value[i], seen);
    }
    return cloned;
  }

  // 普通对象(保留原型链)
  const cloned = Object.create(Object.getPrototypeOf(value));
  seen.set(value, cloned);

  // 克隆自有属性(包括 Symbol 键)
  const ownKeys = [
    ...Object.getOwnPropertyNames(value),
    ...Object.getOwnPropertySymbols(value),
  ];

  for (const key of ownKeys) {
    const descriptor = Object.getOwnPropertyDescriptor(value, key);
    if (descriptor.value !== undefined) {
      Object.defineProperty(cloned, key, {
        ...descriptor,
        value: deepClone(descriptor.value, seen),
      });
    } else {
      // getter/setter:直接复制描述符
      Object.defineProperty(cloned, key, descriptor);
    }
  }

  return cloned;
}

手写验证:深拷贝边界测试

// 全面的边界测试套件
function runCloneTests(cloneFn, name) {
  const tests = [
    {
      desc: '基础对象',
      input: { a: 1, b: 'hello', c: true, d: null },
      check: (original, clone) => {
        return JSON.stringify(original) === JSON.stringify(clone)
          && original !== clone;
      },
    },
    {
      desc: 'Date 保留类型',
      input: new Date('2024-01-15'),
      check: (o, c) => c instanceof Date && c.getTime() === o.getTime(),
    },
    {
      desc: 'RegExp 保留',
      input: /hello/gi,
      check: (o, c) => c instanceof RegExp && c.source === o.source && c.flags === o.flags,
    },
    {
      desc: 'Map 保留',
      input: new Map([['key', 'value'], [1, { nested: true }]]),
      check: (o, c) => c instanceof Map && c.size === o.size,
    },
    {
      desc: 'Set 保留',
      input: new Set([1, 2, 3, { x: 1 }]),
      check: (o, c) => c instanceof Set && c.size === o.size,
    },
    {
      desc: 'undefined 值保留',
      input: { a: undefined, b: 1 },
      check: (o, c) => 'a' in c && c.a === undefined,
    },
    {
      desc: 'NaN 保留',
      input: { value: NaN },
      check: (o, c) => Number.isNaN(c.value),
    },
    {
      desc: '循环引用不崩溃',
      input: (() => { const o = {}; o.self = o; return o; })(),
      check: (o, c) => {
        try { return c.self === c; }
        catch { return false; }
      },
    },
    {
      desc: '深层嵌套',
      input: { a: { b: { c: { d: { e: [1, 2, 3] } } } } },
      check: (o, c) => {
        c.a.b.c.d.e.push(4);
        return o.a.b.c.d.e.length === 3;
      },
    },
    {
      desc: 'Symbol 键',
      input: (() => { const s = Symbol('id'); const o = {}; o[s] = 42; return o; })(),
      check: (o, c) => {
        const oKeys = Object.getOwnPropertySymbols(o);
        const cKeys = Object.getOwnPropertySymbols(c);
        return cKeys.length === oKeys.length;
      },
    },
  ];

  console.log(`\n=== ${name} ===`);
  let passed = 0;

  for (const { desc, input, check } of tests) {
    try {
      const clone = cloneFn(input);
      const ok = check(input, clone);
      console.log(`${ok ? '✅' : '❌'} ${desc}`);
      if (ok) passed++;
    } catch (e) {
      console.log(`❌ ${desc}(异常:${e.message})`);
    }
  }

  console.log(`通过 ${passed}/${tests.length}`);
}

// 对比各方案
runCloneTests(v => JSON.parse(JSON.stringify(v)), 'JSON 深拷贝');
runCloneTests(v => structuredClone(v), 'structuredClone');
runCloneTests(deepClone, '手写 deepClone');

// 结果示例:
// === JSON 深拷贝 ===
// ✅ 基础对象
// ❌ Date 保留类型
// ❌ RegExp 保留
// ❌ Map 保留
// ❌ Set 保留
// ❌ undefined 值保留
// ❌ NaN 保留
// ❌ 循环引用不崩溃(异常:Converting circular structure to JSON)
// ✅ 深层嵌套
// ❌ Symbol 键
// 通过 2/10

// === structuredClone ===
// ✅ 基础对象
// ✅ Date 保留类型
// ✅ RegExp 保留
// ✅ Map 保留
// ✅ Set 保留
// ✅ undefined 值保留
// ✅ NaN 保留
// ✅ 循环引用不崩溃
// ✅ 深层嵌套
// ❌ Symbol 键(DataCloneError)
// 通过 9/10

何时仍需手写深拷贝

// 需要手写深拷贝的场景:

// ① 保留原型链
class CustomError extends Error {
  constructor(msg, code) {
    super(msg);
    this.code = code;
  }
}
const e = new CustomError('失败', 404);
const sc = structuredClone(e); // instanceof CustomError → false(原型丢失)
const dc = deepClone(e);       // instanceof CustomError → true ✅

// ② 克隆包含函数的对象(保留引用)
const store = {
  state: { count: 0 },
  increment() { this.state.count++; },
};
// structuredClone 会抛出 DataCloneError
// deepClone 保留函数引用,但函数不会被复制
const storeCopy = deepClone(store); // increment 是同一引用

// ③ Symbol 属性的保留
const sym = Symbol('private');
const obj = { [sym]: 'secret', public: 'visible' };
const sc2 = structuredClone(obj); // DataCloneError
const dc2 = deepClone(obj);       // { [sym]: 'secret', public: 'visible' } ✅

// ④ getter/setter 的处理
const reactive = {
  _value: 0,
  get value() { return this._value; },
  set value(v) { this._value = v; },
};
const dc3 = deepClone(reactive);
dc3.value = 10; // ✅ setter 仍有效

深度追问

Q1:structuredClone 比 JSON.parse(JSON.stringify()) 慢多少?

通常慢 2-5 倍(取决于数据结构复杂度)。JSON 对于简单对象有 V8 的高度优化路径。但 structuredClone 在处理 ArrayBuffer、Map、Set 等场景时更优,且不存在 JSON 的语义错误(丢失 undefined、NaN 变 null 等)。

选择标准:优先使用 structuredClone,仅在性能 profiling 证明其是瓶颈,且数据满足 JSON 限制时,才降级使用 JSON 方案。

Q2:postMessage 中同时传递普通对象和 ArrayBuffer 时,各自的序列化方式?

普通对象(非 Transferable):使用结构化克隆(深拷贝,O(n))。ArrayBuffer 若在 transfer 列表中:使用所有权转移(O(1),原持有方 detached);若不在 transfer 列表:同样深拷贝。

Q3:为什么 structuredClone 不支持 Symbol 键?

Symbol 是唯一且不可复制的标识符,其语义本身就是"全局唯一"。结构化克隆的目的是在上下文间传递可重建的数据。Symbol 无法在另一个上下文中重建同一 Symbol(除非是 Symbol.for() 的全局 Symbol),因此算法选择抛出错误而非静默丢失。

Q4:history.pushState(state) 的 state 大小有限制吗?

有。规范推荐上限为 640KB,Chrome 实际实现约 2MB。且 state 使用结构化克隆序列化存储在内存中,过大的 state 会增加内存压力。建议 state 中只存 ID,真实数据存在 store 或 URL 参数中。
